ShoeGeometry

Brooks Launch 12

Daily trainerRoadNo plate2026Men'sCurrent

At a glance

Heel-to-toe drop
8 mmDerived
Stack, heel / forefoot
35 / 27 mmStated
Weight
247 gStated
Plate
No plate
Toe rocker
34 % of lengthest.photos 33–38 %
Heel bevel
5.8 % of lengthest.photos 6–8 %
Stiffness / firmness
24 / 65 of 100Derived
Primary foam
DNA Flash (DNA Flash v2 forefoot)

How it compares

  • Brooks Launch 12's heel-to-toe drop is 8 mm, higher than the catalogue median of 6 mm (59% of the 179 other current shoes are lower).
  • Brooks Launch 12's heel stack is 35 mm, thinner than the catalogue median of 38 mm (23% of the 176 other current shoes are thinner).
  • Brooks Launch 12's forefoot stack is 27 mm, thinner than the catalogue median of 31.5 mm (15% of the 171 other current shoes are thinner).
  • Brooks Launch 12's weight is 247 g, lighter than the catalogue median of 269 g (27% of the 167 other current shoes are lighter).
  • 4 shoes with similar geometry from other lines.

Differences smaller than the precision of the sources (about 1 mm of stack, 8 g, or the spread between photos for photo estimates) are reported as about the same.

Specifications

Heel-to-toe drop
Derived
8mm
MediumCalculated
Heel stack
Manufacturer stated
35mm
MediumSpec listingbrand figure, reported by Running Warehousesource
Forefoot stack
Manufacturer stated
27mm
MediumSpec listingbrand figure, reported by Running Warehousesource
Weight
Manufacturer stated
247g
MediumSpec listingbrand figure, reported by Running Warehousesource
Plate
No plate
Primary foam
DNA Flash (DNA Flash v2 forefoot)
List price
$120

Geometry

Catalogue average: heel 38 mm, forefoot 32 mm, toe rocker 35 %Brooks Launch 12: heel 35 mm, forefoot 27 mm (drop 8 mm); toe rocker 34 % of length, radius 43 % of length; heel bevel 6 % of length, 13 mm high at the back, ending behind the heel bone (only the back edge is rounded).35 mm27 mmUnder the centre of the heel bone: 12 % of length from the heel, where heel stack is measuredheel boneHeel contact: the sole is within 4.5 mm of the ground from 6 % of length (foam compresses more under load), ending behind the heel bone (only the back edge is rounded)heel bevel 6 %Toe rocker: the front 34 % of the length curves up (the curve leaves the ground 66 % of length from the heel)toe rocker 34 %toeheel
Front: toe rocker shorter longerRear: heel stack lower higher not measured
Dashed: average of the catalogue
Illustrative profile, not a photograph or scan: drawn to scale for a 300 mm shoe from published stack heights and photo estimates of the unloaded shoe (under body weight the foam compresses and the curves flatten). The grey upper is a generic outline, not this shoe’s. Brooks Launch 12: heel 35 mm, forefoot 27 mm (drop 8 mm); toe rocker 34 % of length, radius 43 % of length; heel bevel 6 % of length, 13 mm high at the back, ending behind the heel bone (only the back edge is rounded). Heel bone: 12 % of length from the heel, where heel stack is measured. Heel bevel and toe rocker are marked where each curve meets the ground; for the heel that is where the sole comes within 4.5 mm of the ground, which foam compression closes under body weight.

Percent values are relative to shoe length so they compare across images and sizes; widths in millimetres are lab measurements from the cited source, while toe tip and heel heights in millimetres are photo estimates converted for a men’s US 9 (assumed 300 mm long), so approximate. See how rocker geometry is defined.

Toe rocker
AI estimated
34%

4 photos range 33–38 %; shown is one of the two that agree most closely.

MediumSide photosource
Rocker radius
AI estimated
43%

4 photos range 42–51 %; shown is one of the two that agree most closely.

MediumSide photosource
Rocker rise angle
AI estimated
27deg

4 photos range 26–28 deg; shown is one of the two that agree most closely.

MediumSide photosource
Toe tip over ground
AI estimated
41mm

4 photos range 39–41 mm; shown is the average of the two that agree most closely.

MediumSide photosource
Rocker angle at toe
AI estimated
54deg

4 photos range 53–54 deg; shown is one of the two that agree most closely.

MediumSide photosource
Visible rocker lift onset
AI estimated
74.9%

4 photos range 74–77.6 %; shown is one of the two that agree most closely.

MediumSide photosource
Toe spring (relative)
AI estimated
18.2%

4 photos range 16.9–18.5 %; shown is one of the two that agree most closely.

MediumSide photosource
Heel bevel length
AI estimated
5.8%

4 photos range 5.8–7.6 %; shown is the average of the two that agree most closely.

MediumSide photosource
Heel bevel height
AI estimated
13mm

4 photos range 12–13 mm; shown is the average of the two that agree most closely.

MediumSide photosource
Midsole width (forefoot)
Externally measured
111mm
MediumLab testsource
Midsole width (heel)
Externally measured
87.4mm
MediumLab testsource
Toe box shape
AI estimated
73%

2 photos range 72–74 %; shown is the average of the two that agree most closely.

LowTop photosource
Interior forefoot width
Externally measured
94mm
MediumLab testsource
Toebox width
Externally measured
70.1mm
MediumLab testsource

Stiffness

Longitudinal stiffness
Derived
24/ 100

Lab reading: 12.6 N, force to bend the shoe 30° (lab bending test); the score is our 0–100 rescaling of it.

MediumLab flex testsource
Midsole firmness
Derived
65/ 100

Lab reading: 37.3 Asker C, midsole durometer reading (higher = firmer); the score is our 0–100 rescaling of it.

MediumLab durometersource

How it compares

Compare:Brooks Launch 12 vs Adidas Supernova Rise 3

Wrong value? Missing data? Tell me
Stored only to improve the site; see privacy.

Sources

  • Brooks Launch 12 Men's Shoes Black/Grey/White | Running WarehouseretailerRunning Warehouseaccessed 2026-10-04open ↗
  • brooks-launch-12 lateral product photoimageRunning Warehouseaccessed 2026-10-04open ↗
  • brooks-launch-12 lateral product photoimageRunning Warehouseaccessed 2026-10-04open ↗
  • brooks-launch-12 medial product photoimageRunning Warehouseaccessed 2026-10-04open ↗
  • brooks-launch-12 medial product photoimageRunning Warehouseaccessed 2026-10-04open ↗
  • Cut in half: Brooks Launch 12 Review (2026) | RunRepeatlabRunRepeataccessed 2026-10-04open ↗
  • brooks-launch-12 sole product photoimageRunning Warehouseaccessed 2026-10-04open ↗
  • brooks-launch-12 top product photoimageRunning Warehouseaccessed 2026-10-04open ↗
Technical detail: every recorded value, method and version (30)

All approved observations

Every recorded value, including superseded ones. The displayed value per metric is chosen by precedence (measured › stated › derived › AI estimated), then confidence, then recency. 58 further observations awaiting review.

MetricValueClassConfidenceMethodSourceRecorded
Heel-to-toe drop8 mmDerivedMediumCalculated—2026-10-04
Heel stack35 mmStatedMediumSpec listingRunning Warehouse2026-10-04
Forefoot stack27 mmStatedMediumSpec listingRunning Warehouse2026-10-04
Weight247 gStatedMediumSpec listingRunning Warehouse2026-10-04
Rocker apex65.6 %est.MediumSide photoRunning Warehouse2026-10-04
Rocker apex66.6 %est.LowSide photoRunning Warehouse2026-10-04
Rocker radius42 %est.LowSide photoRunning Warehouse2026-10-04
Rocker radius43 %est.MediumSide photoRunning Warehouse2026-10-04
Rocker rise angle27 degest.MediumSide photoRunning Warehouse2026-10-04
Rocker rise angle27 degest.LowSide photoRunning Warehouse2026-10-04
Toe tip over ground41 mmest.MediumSide photoRunning Warehouse2026-10-04
Rocker angle at toe54 degest.MediumSide photoRunning Warehouse2026-10-04
Rocker angle at toe54 degest.LowSide photoRunning Warehouse2026-10-04
Toe tip over ground41 mmest.MediumSide photoRunning Warehouse2026-10-04
Visible rocker lift onset74.9 %est.MediumSide photoRunning Warehouse2026-10-04
Visible rocker lift onset74.7 %est.MediumSide photoRunning Warehouse2026-10-04
Toe spring (relative)18.2 %est.MediumSide photoRunning Warehouse2026-10-04
Toe spring (relative)18 %est.MediumSide photoRunning Warehouse2026-10-04
Heel bevel length5.9 %est.MediumSide photoRunning Warehouse2026-10-04
Heel bevel length5.8 %est.MediumSide photoRunning Warehouse2026-10-04
Heel bevel height13 mmest.MediumSide photoRunning Warehouse2026-10-04
Heel bevel height13 mmest.MediumSide photoRunning Warehouse2026-10-04
Midsole width (forefoot)111 mmMeasuredMediumLab testRunRepeat2026-10-04
Midsole width (heel)87.4 mmMeasuredMediumLab testRunRepeat2026-10-04
Toe box shape72 %est.LowTop photoRunning Warehouse2026-10-04
Toe box shape74 %est.LowTop photoRunning Warehouse2026-10-04
Interior forefoot width94 mmMeasuredMediumLab testRunRepeat2026-10-04
Toebox width70.1 mmMeasuredMediumLab testRunRepeat2026-10-04
Longitudinal stiffness24 DerivedMediumLab flex testRunRepeat2026-10-04
Midsole firmness65 DerivedMediumLab durometerRunRepeat2026-10-04

Classes: Manufacturer stated · Externally measured · AI estimated · Derived · User reported. Hover a method for its identifier and algorithm version.

Source notes

  • Running Warehouse: sha256=17e7373023a9623396b5646b3f4dfee1d2129b71f9faaa86c63d4af4bd58f401; 0.3
  • Running Warehouse: sha256=a055e957db04fbb38cdc4dac5f91ede09717745bf4622c951254a75a23dac983; 0.3
  • Running Warehouse: sha256=fce33810097840a74e64b66a9f6c20b279cd5f236de066af8e9e4f78a0fb6629; 0.3
  • Running Warehouse: sha256=7abe233979db87afe2a1cc97c4c20dc247fba12edaa99b4bc85b09550da76b54; 0.3
  • Running Warehouse: sha256=d5a7ed0d4317523e2a3f24e1b8acf7d9c538ba2817adc27859cdc0b7c19e9d93; 0.1
  • Running Warehouse: sha256=6de43e90040f96fb841b67c6bf3c4a5a53544fcaf4825064eed2ced6494aec1d; 0.1

Shoes with similar geometry

Compare these →

Closest current models from other lines by stack, drop, rocker, toe height, stiffness, firmness, weight and width, whichever both shoes have.

Side profile illustration of the VJ FZN Aerofly
VJ
FZN Aerofly
Road/trail hybrid · Rock plate
Drop
8 mm
Heel
38 mm
Toe rocker
—

vs this shoe: 3 mm higher heel

Side profile illustration of the Brooks Glycerin Flex
Brooks
Glycerin Flex
Daily trainer · No plate
Drop
6 mm
Heel
36 mm
Toe rocker
35%

vs this shoe: 2 mm less drop

Side profile illustration of the Brooks Ghost AMP
Brooks
Ghost AMP
Daily trainer · No plate
Drop
6 mm
Heel
36 mm
Toe rocker
33%

vs this shoe: 2 mm less drop

Side profile illustration of the Salomon Aero Blaze 4 GRVL
Salomon
Aero Blaze 4 GRVL
Road/trail hybrid · No plate
Drop
8 mm
Heel
— mm
Toe rocker
33%

Very close on every shared measure
