ShoeGeometry

Nike Structure Plus

StabilityRoadNo plateMen'sCurrent

Specifications

Heel-to-toe drop
Manufacturer stated
10mm
Mediumregex_specs_v2source
Heel stack
Manufacturer stated
42mm
Mediumregex_specs_v2source
Forefoot stack
Manufacturer stated
32mm
Mediumregex_specs_v2source
Weight
Manufacturer stated
295g
Mediumregex_specs_v2source
Plate
No plate
Primary foam
ZoomX over ReactX
List price
$170

Plate, foam and price from Nike Structure Plus Review (2026) - Doctors of Running.

Geometry

Catalogue average: heel 39 mm, forefoot 32 mm, rocker apex 65 %Nike Structure Plus: heel 42 mm, forefoot 32 mm (drop 10 mm); rocker apex 67 % of length, radius 45 % of length.42 mm32 mmRocker apex at 67 % of length from the heelrocker apex 67 %toeheel
Forefoot: rocker apex later earlierRear: heel stack lower higher not measured
Dashed: average of the catalogue
Drawn from the measured values, to scale for a 290 mm shoe; the grey upper is a generic outline, not this shoe’s. Nike Structure Plus: heel 42 mm, forefoot 32 mm (drop 10 mm); rocker apex 67 % of length, radius 45 % of length.

Percent values are relative to shoe length so they compare across images and sizes; millimetre values are lab measurements from the cited source. See how rocker geometry is defined.

Rocker apex
AI estimated
67%
Mediumvision_rocker · 0.3-bc1source
Rocker radius
AI estimated
45%
Mediumvision_rocker · 0.3-bc1source
Rocker rise angle
AI estimated
25deg
Mediumvision_rocker · 0.3-bc1source
Rocker angle at toe
AI estimated
54deg
Mediumvision_rocker · 0.3-bc1source
Toe tip over ground
AI estimated
33mm

Average of two photos 0.7 mm apart.

Mediumvision_rocker · 0.3-bc1source
Visible rocker lift onset
AI estimated
78.2%
Mediumvision_rocker · 0.3-bc1source
Toe spring (relative)
AI estimated
15.5%
Mediumvision_rocker · 0.3-bc1source
Midsole width (forefoot)
Externally measured
119.4mm
Mediumlab_table_widths · 1source
Midsole width (heel)
Externally measured
94.7mm
Mediumlab_table_widths · 1source
Interior forefoot width
Externally measured
93.4mm
Mediumlab_table_widths · 1source
Toebox width
Externally measured
72.5mm
Mediumlab_table_widths · 1source

Stiffness

Longitudinal stiffness
Derived
60/ 100
Mediumlab_bending_force_score · 1source
Midsole firmness
Derived
34/ 100
Mediumlab_midsole_firmness_score · 1source

How it compares

  • Nike Structure Plus's heel-to-toe drop is 10 mm, higher than the catalogue median of 6 mm (88% of the 91 other current shoes are lower).
  • Nike Structure Plus's heel stack is 42 mm, thicker than the catalogue median of 39 mm (74% of the 91 other current shoes are thinner).
  • Nike Structure Plus's forefoot stack is 32 mm, about the catalogue median of 32 mm (43% of the 91 other current shoes are thinner).
  • Nike Structure Plus's weight is 295 g, heavier than the catalogue median of 268 g (76% of the 82 other current shoes are lighter).

Appears in:High drop

Wrong value? Missing data? Tell me
Stored only to improve the site; see privacy.

Sources

  • Nike Structure Plus Review (2026) - Doctors of RunningreviewBlueprintaccessed 2026-10-03open ↗
  • Nike Structure Plus Men's Shoes Navy/Black/Smokey Blue | Running Warehouseretailerrunningwarehouse.comaccessed 2026-10-03open ↗
  • nike-structure-plus medial product photoimageRunning Warehouseaccessed 2026-10-03open ↗sha256=71c4f5c77b47933772e456dc3a10d8efc666f0496c82579661b9ce809dc89049; 0.3
  • nike-structure-plus lateral product photoimageRunning Warehouseaccessed 2026-10-03open ↗sha256=2a5f8686d7c0b1b90dd4ddbb1655f95e21c9dca79d8a8e8b790ebb1a5563eb4b; 0.3
  • nike-structure-plus medial product photoimageRunning Warehouseaccessed 2026-10-03open ↗sha256=6db6570db385530fab2a1d63c47181f2414b2c966513b28997b7d73c05aac820; 0.3
  • nike-structure-plus medial product photoimageRunning Warehouseaccessed 2026-10-03open ↗sha256=39ad1d021102a38fbcbaa8bb6ca75579007942d6db403b776e0d57ccc3c31e73; 0.3
  • nike-structure-plus lateral product photoimageRunning Warehouseaccessed 2026-10-03open ↗sha256=392fcb87039e127c5b4a071f5e439abbcde5d5365cd51de4e235eb44782a7d00; 0.3
  • nike-structure-plus lateral product photoimageRunning Warehouseaccessed 2026-10-03open ↗sha256=83e51bf6a63653bcfbf02d7d809e6d4278a5b27ceae9a04503f5e318b26b371c; 0.3
  • Cut in half: Nike Structure Plus Review (2026) | RunRepeatlabRunRepeat - Athletic shoe reviewsaccessed 2026-10-03open ↗

All approved observations

Every recorded value, including superseded ones. The displayed value per metric is chosen by precedence (measured › stated › derived › AI estimated), then confidence, then recency. 84 further observations awaiting review.

MetricValueClassConfidenceMethodSourceRecorded
Heel-to-toe drop10 mmStatedMediumregex_specs_v2Blueprint2026-10-03
Heel stack42 mmStatedMediumregex_specs_v2Blueprint2026-10-03
Heel stack42 mmStatedMediumregex_specs_v2runningwarehouse.com2026-10-03
Forefoot stack32 mmStatedMediumregex_specs_v2runningwarehouse.com2026-10-03
Forefoot stack32 mmStatedMediumregex_specs_v2Blueprint2026-10-03
Weight295 g (size 9)StatedMediumregex_specs_v2Blueprint2026-10-03
Weight295 gStatedMediumregex_specs_v2runningwarehouse.com2026-10-03
Rocker apex66.7 %est.Mediumvision_rocker 0.3-bc1Running Warehouse2026-10-03
Rocker apex67 %est.Mediumvision_rocker 0.3-bc1Running Warehouse2026-10-03
Rocker radius45 %est.Mediumvision_rocker 0.3-bc1Running Warehouse2026-10-03
Rocker radius45 %est.Mediumvision_rocker 0.3-bc1Running Warehouse2026-10-03
Rocker rise angle25 degest.Mediumvision_rocker 0.3-bc1Running Warehouse2026-10-03
Rocker rise angle25 degest.Mediumvision_rocker 0.3-bc1Running Warehouse2026-10-03
Rocker angle at toe54 degest.Mediumvision_rocker 0.3-bc1Running Warehouse2026-10-03
Toe tip over ground33 mmest.Mediumvision_rocker 0.3-bc1Running Warehouse2026-10-03
Rocker angle at toe53 degest.Lowvision_rocker 0.3-bc1Running Warehouse2026-10-03
Toe tip over ground32 mmest.Lowvision_rocker 0.3-bc1Running Warehouse2026-10-03
Visible rocker lift onset78.2 %est.Mediumvision_rocker 0.3-bc1Running Warehouse2026-10-03
Visible rocker lift onset78.5 %est.Mediumvision_rocker 0.3-bc1Running Warehouse2026-10-03
Toe spring (relative)15.5 %est.Lowvision_rocker 0.3-bc1Running Warehouse2026-10-03
Toe spring (relative)15.5 %est.Mediumvision_rocker 0.3-bc1Running Warehouse2026-10-03
Midsole width (forefoot)119.4 mmMeasuredMediumlab_table_widths 1RunRepeat - Athletic shoe reviews2026-10-03
Midsole width (heel)94.7 mmMeasuredMediumlab_table_widths 1RunRepeat - Athletic shoe reviews2026-10-03
Interior forefoot width93.4 mmMeasuredMediumlab_table_widths 1RunRepeat - Athletic shoe reviews2026-10-03
Toebox width72.5 mmMeasuredMediumlab_table_widths 1RunRepeat - Athletic shoe reviews2026-10-03
Longitudinal stiffness60 DerivedMediumlab_bending_force_score 1RunRepeat - Athletic shoe reviews2026-10-03
Midsole firmness34 DerivedMediumlab_midsole_firmness_score 1RunRepeat - Athletic shoe reviews2026-10-03

Classes: Manufacturer stated · Externally measured · AI estimated · Derived · User reported.
