ShoeGeometry

On Cloudmonster 3

Max cushionRoadNylon plate2026Men'sCurrent

Specifications

Heel-to-toe drop
Manufacturer stated
6mm
Mediumregex_specs_v2source
Heel stack
Manufacturer stated
35mm
Mediumregex_specs_v2source
Forefoot stack
Manufacturer stated
29mm
Mediumregex_specs_v2source
Weight
Manufacturer stated
295g
Mediumregex_specs_v2size 9source
Plate
Nylon plate
Primary foam
Helion
List price
$190

Plate, foam and price from On Cloudmonster 3 Review: Improved, But Barely | Believe in the Run.

Geometry

Catalogue average: heel 39 mm, forefoot 32 mm, rocker apex 65 %On Cloudmonster 3: heel 35 mm, forefoot 29 mm (drop 6 mm); rocker apex 64 % of length, radius 44 % of length.35 mm29 mmRocker apex at 64 % of length from the heelrocker apex 64 %toeheel
Forefoot: rocker apex later earlierRear: heel stack lower higher not measured
Dashed: average of the catalogue
Drawn from the measured values, to scale for a 290 mm shoe; the grey upper is a generic outline, not this shoe’s. On Cloudmonster 3: heel 35 mm, forefoot 29 mm (drop 6 mm); rocker apex 64 % of length, radius 44 % of length.

Percent values are relative to shoe length so they compare across images and sizes; millimetre values are lab measurements from the cited source. See how rocker geometry is defined.

Rocker apex
AI estimated
63.7%
Mediumvision_rocker · 0.3-bc1source
Rocker radius
AI estimated
44%
Mediumvision_rocker · 0.3-bc1source
Rocker rise angle
AI estimated
30deg
Mediumvision_rocker · 0.3-bc1source
Rocker angle at toe
AI estimated
56deg
Lowvision_rocker · 0.3-bc1source
Toe tip over ground
AI estimated
49mm

Average of two photos 0 mm apart.

Lowvision_rocker · 0.3-bc1source
Visible rocker lift onset
AI estimated
73.2%
Lowvision_rocker · 0.3-bc1source
Toe spring (relative)
AI estimated
20.1%
Lowvision_rocker · 0.3-bc1source
Midsole width (forefoot)
Externally measured
113.7mm
Mediumlab_table_widths · 1source
Midsole width (heel)
Externally measured
90.2mm
Mediumlab_table_widths · 1source
Interior forefoot width
Externally measured
94.3mm
Mediumlab_table_widths · 1source
Toebox width
Externally measured
71mm
Mediumlab_table_widths · 1source

Stiffness

Longitudinal stiffness
Derived
66/ 100
Mediumlab_bending_force_score · 1source
Midsole firmness
Derived
100/ 100
Mediumlab_midsole_firmness_score · 1source

How it compares

  • On Cloudmonster 3's heel-to-toe drop is 6 mm, lower than the catalogue median of 7 mm (25% of the 91 other current shoes are lower).
  • On Cloudmonster 3's heel stack is 35 mm, thinner than the catalogue median of 39 mm (15% of the 91 other current shoes are thinner).
  • On Cloudmonster 3's forefoot stack is 29 mm, thinner than the catalogue median of 32 mm (21% of the 91 other current shoes are thinner).
  • On Cloudmonster 3's weight is 295 g, heavier than the catalogue median of 268 g (76% of the 82 other current shoes are lighter).

Appears in:Max cushionEarlier rocker

Compare:On Cloudmonster 3 vs On Cloudmonster 2On Cloudmonster 3 vs Altra Via Olympus 2Previous version: On Cloudmonster 2

What changed from the On Cloudmonster 2

Stack lower, rocker apex starts later, plate changed. Compared with the previous version in this catalogue; differences within measurement noise are shown as about the same.

On Cloudmonster 3: heel 35 mm, forefoot 29 mm (drop 6 mm); rocker apex 64 % of length, radius 44 % of length.On Cloudmonster 3: rocker apex at 64 % of lengthOn Cloudmonster 2: heel 38 mm, forefoot 31 mm (drop 7 mm); rocker apex 59 % of length, radius 48 % of length.On Cloudmonster 2: rocker apex at 59 % of length
  • On Cloudmonster 335/29 mm · apex 64 %
  • On Cloudmonster 238/31 mm · apex 59 %
Midsoles drawn from measured values on a common length (290 mm), heels aligned, toe to the left; dots mark the rocker apex. Dotted lines use typical values where a shoe has no measurement. Exact values are in the table below.
MeasureOn Cloudmonster 2On Cloudmonster 3Change
Heel stack37.9 mm35 mmlower (−2.9 mm)
Forefoot stack31.3 mm29 mmlower (−2.3 mm)
Drop6.6 mm6 mmabout the same
Weight295 g295 gabout the same
Rocker apex58.9% of length63.7% of lengthstarts later (+4.9 %)
Toe tip over ground47.6 mm48.9 mmabout the same
Rocker rise angle27.5°29.9°steeper (+2.5)
Stiffness52/10066/100stiffer (+14)
Firmness100/100100/100about the same
Forefoot base width117.2 mm113.7 mmnarrower (−3.5 mm)
PlateNo plateNylon platechanged
FoamHelion (dual density)Helionchanged

Full side-by-side comparison →

Wrong value? Missing data? Tell me
Stored only to improve the site; see privacy.

Sources

  • On Cloudmonster 3 Review (2026) - Doctors of RunningreviewBlueprintaccessed 2026-10-03open ↗
  • On Cloudmonster 3 Review: Improved, But Barely | Believe in the Runreviewbelieveintherun.comaccessed 2026-10-03open ↗
  • on-cloudmonster-3 lateral product photoimageRunning Warehouseaccessed 2026-10-03open ↗sha256=23b979e26685b17f0ff7923952d7b010b09be96eb776030302130b87b0aea217; 0.3
  • on-cloudmonster-3 lateral product photoimageRunning Warehouseaccessed 2026-10-03open ↗sha256=f632bb30fc2ca4431024ea34b93db21b6400204130baf48851fe537f0b5ace0d; 0.3
  • on-cloudmonster-3 medial product photoimageRunning Warehouseaccessed 2026-10-03open ↗sha256=f2b86dc2dd8c7f1e53353ea3208a4807a6b6300bcbddca1dccaebefa5ceaa09f; 0.3
  • on-cloudmonster-3 medial product photoimageRunning Warehouseaccessed 2026-10-03open ↗sha256=bb01acbaf3e167f785ddeb3a7bc5715674f1c2069ca339e264d4ae672035b1df; 0.3
  • on-cloudmonster-3 lateral product photoimageRunning Warehouseaccessed 2026-10-03open ↗sha256=c26c18138ed72b70252f1b2d451847927205639619c12db13cd1e77c03d3f0c9; 0.3
  • on-cloudmonster-3 medial product photoimageRunning Warehouseaccessed 2026-10-03open ↗sha256=20f41e7688f6a77debdb48c5341e47f1eeb0c86acc0137b1eff5b12ea9d5566b; 0.3
  • Cut in half: On Cloudmonster 3 Review (2026) | RunRepeatlabRunRepeat - Athletic shoe reviewsaccessed 2026-10-03open ↗

All approved observations

Every recorded value, including superseded ones. The displayed value per metric is chosen by precedence (measured › stated › derived › AI estimated), then confidence, then recency. 84 further observations awaiting review.

MetricValueClassConfidenceMethodSourceRecorded
Heel-to-toe drop6 mmStatedMediumregex_specs_v2Blueprint2026-10-03
Heel stack35 mmStatedMediumregex_specs_v2Blueprint2026-10-03
Heel stack35 mmStatedMediumregex_specs_v2believeintherun.com2026-10-03
Forefoot stack29 mmStatedMediumregex_specs_v2Blueprint2026-10-03
Forefoot stack29 mmStatedMediumregex_specs_v2believeintherun.com2026-10-03
Weight295 g (size 9)StatedMediumregex_specs_v2Blueprint2026-10-03
Weight295 g (US M9)StatedMediumregex_specs_v2believeintherun.com2026-10-03
Rocker apex64.1 %est.Lowvision_rocker 0.3-bc1Running Warehouse2026-10-03
Rocker apex63.7 %est.Mediumvision_rocker 0.3-bc1Running Warehouse2026-10-03
Rocker radius44 %est.Lowvision_rocker 0.3-bc1Running Warehouse2026-10-03
Rocker radius44 %est.Mediumvision_rocker 0.3-bc1Running Warehouse2026-10-03
Rocker rise angle30 degest.Mediumvision_rocker 0.3-bc1Running Warehouse2026-10-03
Rocker rise angle30 degest.Lowvision_rocker 0.3-bc1Running Warehouse2026-10-03
Toe tip over ground49 mmest.Lowvision_rocker 0.3-bc1Running Warehouse2026-10-03
Rocker angle at toe56 degest.Lowvision_rocker 0.3-bc1Running Warehouse2026-10-03
Toe tip over ground49 mmest.Lowvision_rocker 0.3-bc1Running Warehouse2026-10-03
Rocker angle at toe56 degest.Lowvision_rocker 0.3-bc1Running Warehouse2026-10-03
Visible rocker lift onset73.1 %est.Lowvision_rocker 0.3-bc1Running Warehouse2026-10-03
Visible rocker lift onset73.2 %est.Lowvision_rocker 0.3-bc1Running Warehouse2026-10-03
Toe spring (relative)20.1 %est.Lowvision_rocker 0.3-bc1Running Warehouse2026-10-03
Toe spring (relative)20.4 %est.Lowvision_rocker 0.3-bc1Running Warehouse2026-10-03
Midsole width (forefoot)113.7 mmMeasuredMediumlab_table_widths 1RunRepeat - Athletic shoe reviews2026-10-03
Midsole width (heel)90.2 mmMeasuredMediumlab_table_widths 1RunRepeat - Athletic shoe reviews2026-10-03
Interior forefoot width94.3 mmMeasuredMediumlab_table_widths 1RunRepeat - Athletic shoe reviews2026-10-03
Toebox width71 mmMeasuredMediumlab_table_widths 1RunRepeat - Athletic shoe reviews2026-10-03
Longitudinal stiffness66 DerivedMediumlab_bending_force_score 1RunRepeat - Athletic shoe reviews2026-10-03
Midsole firmness100 DerivedMediumlab_midsole_firmness_score 1RunRepeat - Athletic shoe reviews2026-10-03

Classes: Manufacturer stated · Externally measured · AI estimated · Derived · User reported.
