ShoeGeometry

Mizuno Wave Sky 9

Max cushionRoadNo plate2025Men'sCurrent

At a glance

Heel-to-toe drop
6 mmDerived
Stack, heel / forefoot
44 / 38 mmStated
Weight
292 gStated
Plate
No plate
Toe rocker
33 % of lengthest.photos 31–35 %
Heel bevel
10.7 % of lengthest.photos 7–11 %
Stiffness / firmness
90 / — of 100Derived
Primary foam
MIZUNO ENERZY NXT (nitrogen-infused EVA) + ENERZY base, Foam Wave

How it compares

  • Mizuno Wave Sky 9's heel-to-toe drop is 6 mm, about the catalogue median of 6 mm (25% of the 179 other current shoes are lower).
  • Mizuno Wave Sky 9's heel stack is 44 mm, thicker than the catalogue median of 38 mm (88% of the 176 other current shoes are thinner).
  • Mizuno Wave Sky 9's forefoot stack is 38 mm, thicker than the catalogue median of 31.5 mm (91% of the 171 other current shoes are thinner).
  • Mizuno Wave Sky 9's weight is 292 g, heavier than the catalogue median of 269 g (74% of the 167 other current shoes are lighter).
  • 4 shoes with similar geometry from other lines.

Differences smaller than the precision of the sources (about 1 mm of stack, 8 g, or the spread between photos for photo estimates) are reported as about the same.

Specifications

Heel-to-toe drop
Derived
6mm
MediumCalculated
Heel stack
Manufacturer stated
44mm
MediumSpec listingbrand figure, reported by Running Warehousesource
Forefoot stack
Manufacturer stated
38mm
MediumSpec listingbrand figure, reported by Running Warehousesource
Weight
Manufacturer stated
292g
MediumSpec listingbrand figure, reported by Running Warehousesource
Plate
No plate
Primary foam
MIZUNO ENERZY NXT (nitrogen-infused EVA) + ENERZY base, Foam Wave
List price
$180

Geometry

Catalogue average: heel 38 mm, forefoot 32 mm, toe rocker 35 %Mizuno Wave Sky 9: heel 44 mm, forefoot 38 mm (drop 6 mm); toe rocker 33 % of length, radius 37 % of length; heel bevel 11 % of length, 20 mm high at the back, ending about under the heel bone.44 mm38 mmUnder the centre of the heel bone: 12 % of length from the heel, where heel stack is measuredheel boneHeel contact: the sole is within 4.5 mm of the ground from 11 % of length (foam compresses more under load), ending about under the heel boneheel bevel 11 %Toe rocker: the front 33 % of the length curves up (the curve leaves the ground 67 % of length from the heel)toe rocker 33 %toeheel
Front: toe rocker shorter longerRear: heel stack lower higher not measured
Dashed: average of the catalogue
Illustrative profile, not a photograph or scan: drawn to scale for a 300 mm shoe from published stack heights and photo estimates of the unloaded shoe (under body weight the foam compresses and the curves flatten). The grey upper is a generic outline, not this shoe’s. Mizuno Wave Sky 9: heel 44 mm, forefoot 38 mm (drop 6 mm); toe rocker 33 % of length, radius 37 % of length; heel bevel 11 % of length, 20 mm high at the back, ending about under the heel bone. Heel bone: 12 % of length from the heel, where heel stack is measured. Heel bevel and toe rocker are marked where each curve meets the ground; for the heel that is where the sole comes within 4.5 mm of the ground, which foam compression closes under body weight.

Percent values are relative to shoe length so they compare across images and sizes; widths in millimetres are lab measurements from the cited source, while toe tip and heel heights in millimetres are photo estimates converted for a men’s US 9 (assumed 300 mm long), so approximate. See how rocker geometry is defined.

Toe rocker
AI estimated
33%

4 photos range 31–35 %; shown is one of the two that agree most closely.

LowSide photosource
Rocker radius
AI estimated
37%

4 photos range 34–42 %; shown is one of the two that agree most closely.

LowSide photosource
Rocker rise angle
AI estimated
33deg

4 photos range 33–36 deg; shown is one of the two that agree most closely.

LowSide photosource
Rocker angle at toe
AI estimated
68deg

4 photos range 65–69 deg; shown is one of the two that agree most closely.

LowSide photosource
Toe tip over ground
AI estimated
46mm

4 photos range 42–46 mm; shown is the average of the two that agree most closely.

LowSide photosource
Visible rocker lift onset
AI estimated
76%

4 photos range 74.8–77.5 %; shown is one of the two that agree most closely.

LowSide photosource
Toe spring (relative)
AI estimated
21.8%

4 photos range 21–24.3 %; shown is one of the two that agree most closely.

LowSide photosource
Heel bevel length
AI estimated
10.7%*

4 photos range 7–10.8 %; shown is the average of the two that agree most closely (* the photos disagree by more than usual).

LowSide photosource
Heel bevel height
AI estimated
20mm

4 photos range 17–20 mm; shown is the average of the two that agree most closely.

LowSide photosource
Midsole width (forefoot)
Externally measured
120mm
MediumLab testsource
Midsole width (heel)
Externally measured
99.9mm
MediumLab testsource
Interior forefoot width
Externally measured
95.7mm
MediumLab testsource
Toebox width
Externally measured
70.4mm
MediumLab testsource

Stiffness

Longitudinal stiffness
Derived
90/ 100

Lab reading: 25.1 N, force to bend the shoe 30° (lab bending test); the score is our 0–100 rescaling of it.

MediumLab flex testsource

How it compares

Appears in:Max cushionHigh stackWide platform

Wrong value? Missing data? Tell me
Stored only to improve the site; see privacy.

Sources

  • Mizuno Wave Sky 9 Men's Shoes Deep Abyss/Silver | Running WarehouseretailerRunning Warehouseaccessed 2026-10-04open ↗
  • mizuno-wave-sky-9 medial product photoimageRunning Warehouseaccessed 2026-10-04open ↗
  • mizuno-wave-sky-9 lateral product photoimageRunning Warehouseaccessed 2026-10-04open ↗
  • mizuno-wave-sky-9 lateral product photoimageRunning Warehouseaccessed 2026-10-04open ↗
  • mizuno-wave-sky-9 medial product photoimageRunning Warehouseaccessed 2026-10-04open ↗
  • Cut in half: Mizuno Wave Sky 9 Review (2026) | RunRepeatlabRunRepeataccessed 2026-10-04open ↗
Technical detail: every recorded value, method and version (27)

All approved observations

Every recorded value, including superseded ones. The displayed value per metric is chosen by precedence (measured › stated › derived › AI estimated), then confidence, then recency. 57 further observations awaiting review.

MetricValueClassConfidenceMethodSourceRecorded
Heel-to-toe drop6 mmDerivedMediumCalculated—2026-10-04
Heel stack44 mmStatedMediumSpec listingRunning Warehouse2026-10-04
Forefoot stack38 mmStatedMediumSpec listingRunning Warehouse2026-10-04
Weight292 gStatedMediumSpec listingRunning Warehouse2026-10-04
Rocker apex66.7 %est.LowSide photoRunning Warehouse2026-10-04
Rocker apex66.6 %est.LowSide photoRunning Warehouse2026-10-04
Rocker radius37 %est.LowSide photoRunning Warehouse2026-10-04
Rocker radius37 %est.LowSide photoRunning Warehouse2026-10-04
Rocker rise angle33 degest.LowSide photoRunning Warehouse2026-10-04
Rocker rise angle33 degest.LowSide photoRunning Warehouse2026-10-04
Toe tip over ground45 mmest.LowSide photoRunning Warehouse2026-10-04
Toe tip over ground46 mmest.LowSide photoRunning Warehouse2026-10-04
Rocker angle at toe69 degest.LowSide photoRunning Warehouse2026-10-04
Rocker angle at toe68 degest.LowSide photoRunning Warehouse2026-10-04
Visible rocker lift onset76.4 %est.LowSide photoRunning Warehouse2026-10-04
Visible rocker lift onset76 %est.LowSide photoRunning Warehouse2026-10-04
Toe spring (relative)21 %est.LowSide photoRunning Warehouse2026-10-04
Toe spring (relative)21.8 %est.LowSide photoRunning Warehouse2026-10-04
Heel bevel length10.6 %est.LowSide photoRunning Warehouse2026-10-04
Heel bevel length10.8 %est.LowSide photoRunning Warehouse2026-10-04
Heel bevel height20 mmest.LowSide photoRunning Warehouse2026-10-04
Heel bevel height20 mmest.LowSide photoRunning Warehouse2026-10-04
Midsole width (forefoot)120 mmMeasuredMediumLab testRunRepeat2026-10-04
Midsole width (heel)99.9 mmMeasuredMediumLab testRunRepeat2026-10-04
Interior forefoot width95.7 mmMeasuredMediumLab testRunRepeat2026-10-04
Toebox width70.4 mmMeasuredMediumLab testRunRepeat2026-10-04
Longitudinal stiffness90 DerivedMediumLab flex testRunRepeat2026-10-04

Classes: Manufacturer stated · Externally measured · AI estimated · Derived · User reported. Hover a method for its identifier and algorithm version.

Source notes

  • Running Warehouse: sha256=84dc345237c1acfa8be42b0979d23140ed1526becfeda69b4df4ba349440aed1; 0.3
  • Running Warehouse: sha256=372fdbc4dfcc695408f659cd09c651164c777b796b2f76efd25524d6316e63cc; 0.3
  • Running Warehouse: sha256=13eee7d89639966b40ffbf55ed3489ce8eec32d7c90b26dbb54144a3f392e4e5; 0.3
  • Running Warehouse: sha256=0f75d9f8b808296f274c3df91473ee3ceb42bcce1be65ea59a4f60ac62463da1; 0.3
